Elan Impression 45.1
Impression 45.1 Exterior
Inspired by the solutions presented on the Elan GT5, the Elan Impression 45.1 now has a longer and wider cockpit, defined by twin wheels, a split cockpit table, and a foldable sunbed. Boasting a modern vertical transom, two large cockpit storage boxes were added, which can also be equipped with a grill, sink, or fridge. Customers can now opt for a sportier look with an open transom configuration or choose the safety and comfort of a closed transom option with a large swim platform. One of the additional changes immediately apparent is the addition of a new window, illuminating the back cabins and building upon her immediately recognizable shape.
Impression 45.1 Interior
The Impression 45.1 is bright and airy, thanks to its hull shape and recognisable deck saloon windows. The saloon features a large settee fully surrounding the table without obstrucitng the pathway. The Galley has been shifted forward, for more spacious living and larger navigation area. After months of testing, iroko veneer framed with solid iroko wood was chosen as the main interior furniture material, because it was determined to have the best endurance capabilities, a beautiful classic look, and an attractive price point. The Elan Impression 45.1 will be available in two cabin layouts, one more aligned with the needs of friends and family, and one for demanding charter groups.
Technicalspecification
| Length Overall | 13.85 m | 45’5’’ ft |
| Hull length | 13.00 m | 42’8’’ ft |
| Length at waterline | 11.44 m | 37’6’’ ft |
| Beam | 4.18 m | 13’9’’ ft |
| Draft | 1.90 m | 6’3’’ ft, (opt1. 1.60m | 5’3’’ ft) |
| Light displacement (mLCC) | 10.420 kg | 23.0 lbs |
| Air Draft (incl. antenna) | 19.50 m | 63’12’’ ft |
| Ballast | 3.310 kg | 7.3 lbs or 3.450 kg | 7.6 lbs |
| Water capacity (standard) | 516 liters | 136,3 US gal |
| Water capacity (option) | 788 liters | 208,2 US gal |
| Fuel capacity | 215 liters | 56 US gal |
| Engine Volvo (standard) | 37 kW | 50 HP |
| Engine Yanmar (standard) | 42 kW | 57 HP |
| Engine Volvo (option) | 55 kW | 75 HP |
| Mainsail | 46.79 m2 | 503’6’’ sq ft |
| Furling | 39.75 m2 | 427’9’’ sq ft |
| Genoa | 52.47 m2 | 564’7’’ sq ft |
| Gennaker | 135.45 m2 | 1458’0’’ sq ft |
| I | 15.90 m | 52’2’’ ft |
| J | 4.78 m | 15’8’’ ft |
| P | 14.80 m | 48’7’’ ft |
| E | 5,37 m |17’7’’ ft |
